1 SCA112710R1001txheeb xyuas qhov ABB OTM2500E3CM230C lub cev muaj zog hloov pauv- dhau kev hloov tsim los rau siab- daim ntawv thov hloov hluav taws xob tam sim no.
Qhov kev txiav txim ua tiav sawv cev rau ib qho kev teeb tsa OTM tshwj xeeb, sib txuas cov qauv hloov pauv loj, kev teeb tsa ncej, lub cev muaj zog ua haujlwm, thiab tswj qhov ntsuas hluav taws xob.
Tsis zoo li cov pa disconnectors lossis contactors siv rau kev hloov hluav taws xob, cov cuab yeej no koom nrog ABB hloov pauv cov khoom siv uas qhov kev txheeb xyuas qhov tseem ceeb yog kev hloov pauv ua ke nrog cov tshuab ua haujlwm.
Rau kev lag luam cov ntaub ntawv khaws tseg, tag nrho ABB tsab xov xwm ib txwm khaws cia vim tias cov OTM sib txawv sib txawv tuaj yeem faib cov qauv sab nraud zoo sib xws thaum muaj qhov sib txawv tam sim no, tus lej xov tooj, lossis txoj kev khiav haujlwm.
Technical Data Record
| Cov khoom kaw tseg | Specification |
|---|---|
| Chaw tsim tshuaj paus | ABB |
| Order Number | 1 SCA112710R1001 |
| Kev tsim khoom | OTM2500E3CM230C |
| Tsev neeg khoom | OT Motorized Hloov-Over Switches |
| Ntaus hom | Motorized C / O Hloov |
| Rated Tam sim no | 2500 A |
| Number of Poles | 3 Poles |
| Lub cev muaj zog ua haujlwm | Integrated Tsav Tsav |
| Motor Control Voltage | 220-240V AC |
| Rated rwb thaiv tsev Voltage (Ui) | 1000 V |
| Rated Ua Haujlwm Voltage (Ue) | Mus txog 1000 V |
| Luv -Lub Sijhawm Nrog Tam Sim No (Icw) | 55k ua |
| Mounting Style | Vaj huam sib luag Installation |
| Pem hauv ntej tiv thaiv Degree | IP20 |
Qauv Configuration Breakdown
Lub npe OTM2500E3CM230C muab cov ntsiab lus qhia txog tus kheej.
| Qauv Element | Kev piav qhia |
|---|---|
| OTM | ABB motorized hloov- dhau tsev neeg hloov |
| 2500 | Tam sim no tus ncej ntsuas |
| E3 | Peb - ncej configuration |
| C | Hloov- dhau qhov hloov pauv |
| M | Motorized ua haujlwm |
| 230C | Lub cev muaj zog ua haujlwm voltage variant |
Tus qauv code yog siv los qhia qhov txawv ntawm chav tsev no los ntawm lwm qhov kev teeb tsa OTM uas muaj peev xwm sib txawv tam sim no lossis phau ntawv ua haujlwm.
Hloov Kev Npaj
Cov cuab yeej no tau teeb tsa raws li kev hloov pauv- dhau qhov hloov pauv hloov tsis yog tus qauv qhib / tawm cais tawm.
| Muaj nuj nqi | Kev piav qhia |
|---|---|
| Hloov hom | Hloov- dhau kev ua haujlwm |
| Main Circuit Ncej | 3 |
| Kev ua haujlwm hom | Tsav tsheb |
| Kev tuav haujlwm | Muaj los ntawm kov mechanism |
| Hloov Txoj Haujlwm | II-0- II |
Kev sib xyaw ua ke ntawm lub cev muaj zog tso cai rau hluav taws xob ua haujlwm ntawm txoj haujlwm hloov, thaum muaj peev xwm ua haujlwm tau suav nrog rau kev tuav hauv zos.
Nrhiav tsis tau lub version koj xav tau?
Cov Ntaub Ntawv Muaj Peev Xwm Hluav Taws Xob
OTM2500E3CM230C belongs rau qhov siab - ntu tam sim no ntawm ABB OT hloov pauv tsev neeg.
| Parameter | Tus nqi |
|---|---|
| Chav kawm tam sim no | 2500 A |
| Chav Kawm Voltage | 1000 V |
| Ncej Configuration | Peb Theem |
| Kev sib txuas ntawm Terminal | Ntsia Hlau Txuas |
| Luv luv -Nyob tam sim no Rating | 55k ua |
ABB OTM motorized hloov-dhau switches muaj nyob rau hauv ntau qhov ntau thiab tsawg thiab configurations.
Qhov sib txawv tseem ceeb ntawm OTM qauv suav nrog:
| Xaiv cheeb tsam | Muaj Variations |
|---|---|
| Kev ntsuas tam sim no | Cov chav kawm txawv ampere |
| Ncej Number | Kev hloov pauv sib txawv |
| Txoj Kev Ua Haujlwm | Phau ntawv los yog motorized |
| Tswj Voltage | Txawv lub cev muaj zog versions |
| Installation Format | Vaj huam sib luag mounting xaiv |
OTM2500E3CM230C sawv cev rau ib qho tshwj xeeb siab -tam sim no motorized configuration.
Kev txheeb xyuas ua ntej hloov
Thaum kuaj xyuas qhov hloov pauv uas twb muaj lawm rau kev hloov pauv, cov ntaub ntawv hauv qab no yuav tsum raug txheeb xyuas:
| Xyuas yam khoom | Yog vim li cas |
|---|---|
| ABB Tshooj Naj Npawb | Paub meej tias kev teeb tsa |
| Kev ntsuas tam sim no | Match zog muaj peev xwm |
| Number of Poles | Paub meej txog kev teeb tsa Circuit Court |
| Lub cev muaj zog | Match kev khiav hauj lwm mechanism |
| Hloov hom | Paub meej tias kev hloov pauv- dhau kev ua haujlwm |
| Txee Dimensions | Xyuas kom tseeb tias installation compatibility |
Rau cov cuab yeej hloov pauv loj tam sim no, sib piv tsuas yog qhov ntsuas ampere tsis txaus vim tias cov khoom siv sib txawv tuaj yeem muaj nyob hauv tib tsev neeg cov khoom.
Component Classification
| Qeb | Paub meej |
|---|---|
| Hom | ABB |
| Hom Lub Npe | Hloov & Disconnectors |
| Tsev neeg khoom | OT Hloov Hloov Hloov |
| Series | OTM |
| Hom Lub Npe | Motorized Hloov-Over Switch |
| Cov khoom siv muaj nuj nqi | Fais fab Hloov Hloov Hloov |
